Thrust Ball Bearings 230000 B BM Series

Double direction angular contact thrust ball bearings are designed to locate spindle shafts axially in both directions. These bearings are intended for mounting in combination with cylindrical roller bearings, and consist of two single row angular contact thrust ball bearings arranged back-to-back. The large number of balls enables these bearings to accommodate high axial loads in both directions and provides a high degree of system rigidity.

Category：

Thrust Ball Bearings

+86-15265513831

sale@shangzhibearing.com

E-mail

Message

Product Description

Product Details

Bearing Number	d	D	B
	(mm)	(mm)	(mm)
234407B	35	62	34
234408B	40	68	36
234409B	45	75	38
234410B	50	80	38
234411B	55	90	44
234412B	60	95	44
234413B	65	100	44
234414B	70	110	48
234415B	75	115	48
234416B	80	125	54
234417B	85	130	54
234418B	90	140	60
234419B	95	145	60
234420B	100	150	60
234421B	105	160	66
234422B	110	170	72
234424B	120	180	72
234426B	130	200	84
234428B	140	210	84
234430B	150	225	90
234432B	160	240	96
234438B	190	290	120
234440B	200	310	132
234705B	27	47	28
234706B	32	55	32
234707B	37	62	34
234708B	42	68	36
234709B	47	75	38
234710B	52	80	38
234711B	57	90	44
234712B	62	95	44
234713B	67	100	44
234714B	73	110	48
234715B	78	115	48
234716B	83	125	54
234717B	88	130	54
234718B	93	140	60
234719B	98	145	60
234720B	103	150	60
234721B	109	160	66
234722B	114	170	72
234724B	124	180	72
234726B	135	200	84
234728B	145	210	84
234730B	155	225	90
234732B	165	240	96
234738B	197	290	120
234740B	207	310	132
234406BM	30	55	32
234706BM	32	55	32
234407BM	35	62	34
234707BM	37	62	34
234408BM	40	68	36
234708BM	42	68	36
234409BM	45	75	38
234709BM	47	75	38
234410BM	50	80	38
234710BM	52	80	38
234411BM	55	90	44

Product Testing
